Overview
Made in Canada
3.5 kg Warranty: 12 months
Complex Device, Tailored Solutions: We're Here to Help!
This device is highly sophisticated. If needed, we're ready to assist you in finding the best model for your specific needs.
Green/red LED indicator gives you a pass or fail test verdict according to the thresholds you have defined, for faster and easier field operation. Read more
Discontinued
Description
EXFO FPM-602 is a Power Meter designed for link and system qualification. Green/red LED indicator gives you a pass or fail test verdict according to the thresholds you have defined, for faster and easier field operation.
Features
- High accuracy, wide dynamic range and high power measurement capability.
- Memory capacity of 1000 data items; enables data transfer to a PC via USB connection.
- User-configurable pass/fail thresholds with LED indicator.
- Over 40 calibrated wavelengths, and Hold Min/Max Power function.
- Error-free, time-saving test features: automatic wavelength switching, no offset nulling.
- Rechargeable batteries.
Technical Specifications
| Detector | Ge |
| Power range | 10 to –70 dBm |
| Wavelength range | 800 to 1650 nm |
| Calibrated wavelengths | 800, 820, 830, 840, 850, 860, 870, 880, 910, 980, 1270, 1280, 1290, 1300, 1310, 1320, 1330, 1340, 1350, 1370, 1390, 1410, 1430, 1450, 1460, 1470, 1480, 1490, 1500, 1510, 1520, 1530, 1540, 1550, 1560, 1570, 1580, 1590, 1600, 1610, 1620, 1630, 1640, 1650 |
| Power uncertainty | ±5 % ± 0.1 nW |
| Resolution | ±0.01 dB (10 dBm to –60 dBm) |
| Automatic offset nulling | Yes |
| Display units | dB, dBm, W |
| Tone detection | 270 Hz, 1 kHz and 2 kHz |
| Auto-switching | Yes |
| Warm-up period | 0 min |
| Data storage | more than 1000 items |
| Battery life (typical) | 72 hours |
| Temperature | operating: –10 °C to 50 °C, storage: –40 °C to 70 °C |
| Relative humidity | 0 % to 95 % non-condensing |
| Size (H x W x D) | 190 mm x 100 mm x 62 mm |
| Weight | 0.48 kg |
