Digital Clamp Meter Minipa ET-3700

id: 856649
1 kg Warranty: 36 month (s)
The reliable digital clamp meter measures AC/DC voltage, AC current, resistance, frequency, and performes diode check and continuity test.
USD 35.00
Notify
when in stock
USD 35.00
Notify
when in stock
Add to wishlist
Compare
Compare
Impossible to estimate the shipping cost
Overview
Specifications
Substitution
Video
Delivery
Payment
Warranty
Overview

Minipa ET-3700 is reliable digital clamp meter that is designed for measuring AC/DC voltage, AC current, resistance, frequency, and performes diode check and continuity test.

Features

  • Measuring functions:
    • AC current
    • AC/DC voltage
    • resistance
    • frequency
    • continuity test (with buzzer)
    • diode test
  • Auto ranging
  • Relative measurements mode
  • Data Hold function
  • Low battery indication

Techical Specifications

Jaw size 57 mm
DC voltage Range 4 V / 40 V / 400 V / 1000 V
Accuracy ±(1.0%+3)
AC voltage Range 4 V / 40 V / 400 V / 750 V
Accuracy ±(1.5%+5)
AC current Range 400 A / 2000 A
Accuracy ±(2.0%+5)
Resistance Range 400 Ω / 4 kΩ / 40 kΩ / 400 kΩ / 4 MΩ
Accuracy ±(1.0%+3)
Frequency Range 100 Hz ~ 1 MHz
Accuracy ±(0.5%+4)
Power 9 V battery (6F22)
Dimensions 280 × 106 × 50 mm
Weight 610 g

Video

Youtube video

Package Contents

  • Minipa ET-3700 clamp meter module (1 pc.)
  • Test lead (1 pair.)
  • 6F22 battery (1 pc.)
  • User manual (1 pc.)
Specifications
Digit Capacity
  • 3999
Type
  • for AC
Jaw diameter
  • diameter 55 mm
DC Voltage
  • up to 1000 V
AC Voltage
  • up to 750 V
Resistance
  • up to 40 MOhm
Capacitance
  • does not measure the capacitance
DC
  • does not measure the DC
Temperature
  • no
Power
  • no
Duty cycle
  • no
True RMS
  • no
Backlight
  • no
PC connection
  • no connection to PC
Diode test
  • yes
Analog bar graph
  • no
Continuity test
  • yes
AC
  • up to 2000 A
Three-phase voltage measurement
  • no
Three-phase current measurement
  • no
Frequency
  • up to 5 MHz
NCV
  • no
Video
Youtube video
