Digital Clamp Meter UNI-T UT210E

id: 866950
Digital Clamp Meter UNI-T UT210E
Overview
Description
Specifications
Video
Delivery
Payment
Warranty
USD 45.66
Add to cart
Overview
Bestseller
4.5 (4)
Rate product
0.8 kg
Availability in stock: HK
Warranty: 24 months
Mini True RMS digital clamp meter for conducting current, voltage, resistance and capacitance measurements, as well as diode and continuity test. Read more
USD 45.66
Add to cart
Add to wishlist
Compare
Compare
USD 45.66
Add to cart
Impossible to estimate the shipping cost

Frequently bought together

Tweezers Measuring Probe UNI T UT L01
Add to wishlist
ID: 834649
Tweezers Measuring Probe UNI-T UT-L01
USD 3.92
Add to wishlist
Add to cart
Tweezers-type measuring probe for SMD component measuring with UNI-T measuring equipment.
Availability in stock: HK
Shipping cost
ID: 834649 0.061 kg
Description

UNI-T UT210E is a mini True RMS digital clamp meter for conducting current, voltage, resistance and capacitance measurements, as well as diode and continuity test.

Features

  • Test and measuring functions:
    • AC Current
    • DC Current
    • AC Voltage
    • DC Voltage
    • Resistance
    • Capacitance
    • Diode test
    • Continuity test
  • True RMS
  • Auto Range function
  • Data Hold function
  • Continuity Buzzer
  • LCD Backlight
  • Auto Power Off
  • Low Battery Indication
  • Input Protection

Technical Specifications

Function Range Accuracy
AC Current 20 A / 100 A ±(2.5%+5)
DC Current 20 A / 100 A ±(2%+3)
AC Voltage 2 V / 20 V / 200 V / 600 V ±(1%+3)
DC Voltage 200 MV / 2 V / 20 V / 200 V / 600 V ±(0.7%+3)
Resistance 200 Ω / 2 kΩ / 20 kΩ / 200 kΩ / 2 MΩ / 20 MΩ ±(1.0%+2)
Capacitance 2 nf / 20 nf / 200 μf / 2 mf / 20 mf ±(4%+5)
General Characteristics
Jaw opening capacity ~ 17 mm
Input Impedance for DCV ≥ 10 MΩ
Power AAA 1.5V × 2
Display LCD, 39.3 mm × 26.5 mm
Size 175 × 60 × 33.5 mm
Weight 170 g

Video

Youtube video

You'll find even more video reviews in the Video tab. Go and check it out!

Package Contents

  • UNI-T UT210E digital clamp meter — 1 pc.
  • Test  Leads — 1 set
  • Carrying Bag — 1 pc.
  • Manual — 1 pc.

Note! Batteries are not included in the package.

Specifications
Digit Capacity
  • 1999
Type
  • for AC/DC
DC Voltage
  • up to 600 V
AC Voltage
  • up to 600 V
Resistance
  • up to 200 MOhm
Capacitance
  • up to 20 000 µF
Frequency
  • does not measure the frequency
Temperature
  • no
Power
  • no
Duty cycle
  • no
True RMS
  • yes
Backlight
  • yes
PC connection
  • no connection to PC
Diode test
  • yes
Analog bar graph
  • no
Continuity test
  • yes
Jaw diameter
  • diameter 17 mm
Three-phase voltage measurement
  • no
Three-phase current measurement
  • no
DC
  • up to 100 A
AC
  • up to 100 A
NCV
  • yes
