Digital Multimeter Pro'sKit 3PK-8205C
id: 7510
Digital Multimeter Pro'sKit 3PK-8205C
Overview
Description
Specifications
Video
Delivery
Payment
Warranty
Discontinued
Contact
sales team
sales team
Overview
Video
Video
0.65 kg Warranty: 6 months
High measuring accuracy. 38 graphic segments. Automatic ranging. Automatic shutdown. Error signal. Illumination.
Description
Digital multimeter Pro'sKit 3PK – 8205C with automatic ranging provides high measurement accuracy. Automatic shutdown. Error signal. Display illumination.
Video
You'll find even more video reviews in the Video tab. Go and check it out!
Technical specifications
| Ranging | automatic/manual |
| Counts | 3999 |
| DC voltage | 4/40/400 V ±0.7% 1000 V ±1.0% |
| AC voltage | 4/40/400 V ±1.2% 1000 V ±1.5% |
| DC current | 4/40/400 mA ±1.2% 10 A ±2.0% |
| AC current | 4/40/400 mA ±1.5% 10 A ±3.0% |
| Resistance | 400 Ω/4/400 kΩ/4 MΩ ±1.2% 40 MΩ ±3.0% |
| Temperature measurement range t°C | -20~0 °C ±5.0% 0~400 °C/400~1000 °C ±3.0% |
| Capacitance | 4 n/400 nF±4.0% |
| Conductivity wire identification | yes |
| Diode, transistor test | yes |
| Automatic power-off | yes |
| Data Hold | yes |
| Charge battery indication | yes |
| Display illumination | yes |
| Power source | 6 F22 (9 V) |
| Dimensions | 191 × 82 × 36 mm |
Read more
Description
Digital multimeter Pro'sKit 3PK – 8205C with automatic ranging provides high measurement accuracy. Automatic shutdown. Error signal. Display illumination.
Video
You'll find even more video reviews in the Video tab. Go and check it out!
Technical specifications
| Ranging | automatic/manual |
| Counts | 3999 |
| DC voltage | 4/40/400 V ±0.7% 1000 V ±1.0% |
| AC voltage | 4/40/400 V ±1.2% 1000 V ±1.5% |
| DC current | 4/40/400 mA ±1.2% 10 A ±2.0% |
| AC current | 4/40/400 mA ±1.5% 10 A ±3.0% |
| Resistance | 400 Ω/4/400 kΩ/4 MΩ ±1.2% 40 MΩ ±3.0% |
| Temperature measurement range t°C | -20~0 °C ±5.0% 0~400 °C/400~1000 °C ±3.0% |
| Capacitance | 4 n/400 nF±4.0% |
| Conductivity wire identification | yes |
| Diode, transistor test | yes |
| Automatic power-off | yes |
| Data Hold | yes |
| Charge battery indication | yes |
| Display illumination | yes |
| Power source | 6 F22 (9 V) |
| Dimensions | 191 × 82 × 36 mm |
