Digital Multimeter UNI-T UT53
UNI-T UT53 Digital Multimeter is a high-quality multifunction digital multimeter. This convenient portable device is powered from a 9 V battery. UNI-T UT53 is characterized by multiple measurements (voltage, current, resistance, capacitance, temperature) and tests (diode, transistor, continuity) and auto power-off function.
UNI-T UT53 Digital Multimeter Features
UNI-T UT53 Digital Multimeter is a high-quality multifunction digital multimeter. This convenient portable device is powered from a 9 V battery. UNI-T UT53 is characterized by multiple measurements (voltage, current, resistance, capacitance, temperature) and tests (diode, transistor, continuity) and auto power-off function.
UNI-T UT53 Digital Multimeter Features
- Compact and lightweight device.
- 3 ½ digit LCD display.
- Auto power-off function.
- Multiple measurements:
- AC Voltage.
- DC Voltage.
- AC Current.
- DC Current.
- Resistance.
- Capacitance.
- Temperature.
- Diode testing.
- Transistor test.
- Continuity test.
- Sleep mode.
- Continuity beeper.
- Battery power.
- Easy to connect and operate.
- Electrical safety: EN61010-1, CATII600V/CATI1000V.
Video
You'll find even more video reviews in the Video tab. Go and check it out!
UNI-T UT53 Digital Multimeter User Manual
Download UNI-T UT53 Digital Multimeter User Manual.
UNI-T UT53 Digital Multimeter Technical Specifications
| Function | Range | Accuracy |
|---|---|---|
| DC Voltage | 200 mV/2 V/20 V/200 V/1000 V | ±(0.5%+3) |
| AC Voltage | 200 mV/2 V/20 V/200 V/750 V | ±(0.8%+3) |
| DC Current | 2 mA/20 mA/200 mA/20 A | ±(0.8%+1) |
| AC Current | 20 mA/200 mA/20 A | ±(1%+3) |
| Resistance | 200 Ω/2 kΩ/20 kΩ/200 kΩ/2 MΩ/20 MΩ/200 MΩ | ±(0.8%+1) |
| Capacitance | 2 nF/20 nF/200 nF/2 μF/20 μF | ±(1%+3) |
| Temperature | –20°C to 1000°C | ±(1%+3) |
| Imput Impedance for DC Voltage Measurement | 10 MΩ | |
| General Characteristics | ||
| Power | 9V Battery (6F22) | |
| Display | LCD, 33 × 65 mm | |
| Size | 190 × 88 × 34 mm / 7.48 × 3.46 × 1.34 in | |
| Weight | 580 g | |
UNI-T UT53 Digital Multimeter Package Contents
- UNI-T UT53 Digital Multimeter Unit (1 pc.)
- Test leads (2 pcs.)
- Temperature probe (1 pc.)
- Holster (1 pc.)
- User manual (1 pc.)
Note! Batteries are not included in the package.
