Digital Multimeter UNI-T UT890C

Name: Digital Multimeter UNI-T UT890C
Brand: UNI-T
SKU: 893958
Price: 14.96 USD
Availability: OutOfStock
Rating: 4.8 (5 reviews)

id: 893958

Overview

Description

Specifications

Delivery

Payment

Warranty

USD 14.96

Overview

Digital Multimeter UNI-T UT890C Preview 1

Digital Multimeter UNI-T UT890C Preview 2

Digital Multimeter UNI-T UT890C Preview 3

Digital Multimeter UNI-T UT890C Preview 4

4.8 (5)

Brand:

0.5 kg Warranty: 24 months

True RMS multimeter for measuring AC/DC voltage & current, resistance, frequency, capacitance, temperature, and performing hFE, diode, continuity tests. Read more

USD 14.96

Impossible to estimate the shipping cost

Description

UNI-T UT890C is a 6000-count True RMS digital multimeter with a large LCD for measuring AC/DC voltage & current, resistance, frequency, capacitance, temperature, and performing hFE, diode, continuity tests.

Features

True RMS measurements.
Manual Range
NCV and continuity measurements (with sound and light indication).
Diode test
hFE test.
MAX/MIN/REL mode.
Data Hold function.
High voltage protection.
Fuse blowing alarm.
Over-current alarm (≥20 A).
Low battery indication (≤2.5 V).
Auto power off function (after 15 minutes).
LCD backlight.

Technical Specifications

Function	Range	Accuracy
DC Voltage	600 mV / 6 V / 60 V / 600 V / 1000 V	±(0.5%+2)
AC Voltage	6 V / 60 V / 600 V / 750 V	±(0.8%+3)
ACV Frequency	10 Hz～10 kHz	±(0.1%+5)
DC Current	60 μA / 600 μA / 6 mA / 60 mA / 600 mA / 20 A	±(0.8%+8)
AC Current	60 μA / 600 μA / 6 mA / 60 mA / 600 mA / 20 A	±(1%+12)
Resistance	600 Ω / 6 kΩ / 60 kΩ / 600 kΩ / 6 MΩ / 60 MΩ	±(0.8%+3)
Capacitance	6.000 nF / 60.00 nF / 600.0 nF / 6.000 μF / 60.00 μF / 600.0 μF / 6.000 mF / 60.00 mF / 100.0 mF	±(3%+10)
Frequency	9.999 Hz～9.999 MHz	±(1.0%+5)
Temperature	–40°C~1000°C/–40°F~1832°F	±(1.5%+5)
General Characteristics
Power Supply	1.5 V battery x 2
Working temperature	0°C～40°C
Display	LCD, 48 × 16 mm
Size	183 × 88 × 56 mm
Weight	346 g

User Manual

Download UNI-T UT890C user manual.

Package Contents

UNI-T UT890C Digital Multimeter — 1 pc.
Measuring Probes — 1 set
AAA 1,5V Batteries — 2 pcs.
Thermocouple — 1 pc.
User Manual — 1 pc.

Specifications

Type	digital
Range Selection	manual range
Digit Capacity	5999
DC Voltage	up to 1000 V
AC Voltage	up to 750 V
Resistance	up to 60 MOhm
Capacitance	up to 100 μF
Frequency	up to 10 MHz
DC	up to 20 A
AC	up to 20 A
Inductance	no
Temperature	yes
Power	no
Duty cycle	no
True RMS	yes
Backlight	yes
PC connection	no connection to PC
Diode test	yes
Analog bar graph	no
Transistor check	yes
Continuity test	yes
NCV	yes
Battery Testing	no
