Overview
6.5 kg 110, 220 V Warranty: 24 months
Desktop 2 channel digital storage oscilloscope. Bandwidth 25 MHz. Sampling rate 1 GSa/s. Memory depth: 40 Kpts. Display: 7" TFT.
USD 270.00
Contact
sales team
Compare
Compare
USD 270.00
Contact
sales team
Impossible to estimate the shipping cost
Description

ATTEN GA1022CAL is a desktop digital storage oscilloscope. It has 2 channels, 25 MHz bandwidth, sampling rate of 1 GSa/s and 40 Kpts memory depth.

Features

  • 1 GSa/s sampling rate.
  • 2 channels.
  • 7-inch widescreen color TFT LCD (800 x 480).
  • Memory depth: single channel: 40 Kpts; double channels: 20 Kpts.
  • Various trigger functions: Edge, Pulse, Video, Slope and Alternative.
  • Unique digital filtering and waveform recording functions.
  • Supports Pass/Fail function.
  • 32 kinds of automatic measurement and manual cursor tracking measurement functions.
  • Two groups of reference waveforms, 16 groups of common waveforms, 20 groups of internal storage/output; support waveform setting, external storage and output of CSV and bitmap file by USB flash disc (CSV and bitmaps cannot be output from USB flash disc).
  • Adjustable waveform brightness and screen grid brightness.
  • Various kinds of language interface display, Chinese and English.
  • On-line help system.
  • Easyscope Software.
  • Shortcut key to PRINT, supports print screen.
  • PictBridge function.
  • Standard configuration interfaces:
    • USB Host: supports storage of USB flash disc and upgrading of USB flash disc system software;
    • USB Device: supports PC connection for remote communication;
    • RS-232.

Technical Specifications

Channels 2
Sampling Rate 1 GSa/s
Bandwidth 25 MHz
Memory depth single channel: 40 Kpts; double channels: 20 Kpts
Trigger functions Edge, Pulse, Video, Slope, Alternative
Display 7" color TFT LCD (800 x 480)
Interfaces USB Host, USB Device, RS-232

Package Contents

  • Digital Oscilloscope ATTEN GA1022CAL — 1 pc.
  • Probes 1×1 / 1×10 — 2 pcs.
  • Power cord — 1 pc.
  • USB cable — 1 pc.
  • CD with Software — 1 pc.
  • User's Manual — 1 pc.
Read more
Description

ATTEN GA1022CAL is a desktop digital storage oscilloscope. It has 2 channels, 25 MHz bandwidth, sampling rate of 1 GSa/s and 40 Kpts memory depth.

Features

  • 1 GSa/s sampling rate.
  • 2 channels.
  • 7-inch widescreen color TFT LCD (800 x 480).
  • Memory depth: single channel: 40 Kpts; double channels: 20 Kpts.
  • Various trigger functions: Edge, Pulse, Video, Slope and Alternative.
  • Unique digital filtering and waveform recording functions.
  • Supports Pass/Fail function.
  • 32 kinds of automatic measurement and manual cursor tracking measurement functions.
  • Two groups of reference waveforms, 16 groups of common waveforms, 20 groups of internal storage/output; support waveform setting, external storage and output of CSV and bitmap file by USB flash disc (CSV and bitmaps cannot be output from USB flash disc).
  • Adjustable waveform brightness and screen grid brightness.
  • Various kinds of language interface display, Chinese and English.
  • On-line help system.
  • Easyscope Software.
  • Shortcut key to PRINT, supports print screen.
  • PictBridge function.
  • Standard configuration interfaces:
    • USB Host: supports storage of USB flash disc and upgrading of USB flash disc system software;
    • USB Device: supports PC connection for remote communication;
    • RS-232.

Technical Specifications

Channels 2
Sampling Rate 1 GSa/s
Bandwidth 25 MHz
Memory depth single channel: 40 Kpts; double channels: 20 Kpts
Trigger functions Edge, Pulse, Video, Slope, Alternative
Display 7" color TFT LCD (800 x 480)
Interfaces USB Host, USB Device, RS-232

Package Contents

  • Digital Oscilloscope ATTEN GA1022CAL — 1 pc.
  • Probes 1×1 / 1×10 — 2 pcs.
  • Power cord — 1 pc.
  • USB cable — 1 pc.
  • CD with Software — 1 pc.
  • User's Manual — 1 pc.
Specifications
Screen Size
  • 7.0" TFT display
Number of channels
  • dual-channel
Storage Capacity
  • 40 kB
Bandwidth
  • 25 MHz
Type
  • desktop
Sample Rate
  • 1 GS/s
