Digital Oscilloscope RIGOL DS2102A-S

id: 845102
8.5 kg 110, 220 V Warranty: 36 month (s)
Dual-channel digital oscilloscope with 100 MHz bandwidth, 2 GSa/s real-time sample rate, built-in dual-channel signal generator, 8" display and 50,000 waveforms/sec acquisition.
USD 1489.00
Contact
sales team
USD 1489.00
Contact
sales team
Add to wishlist
Compare
Compare
Impossible to estimate the shipping cost
Overview
Specifications
Video
Delivery
Payment
Warranty
Overview

RIGOL DS2102A-S digital oscilloscope is a new high-quality dual-channel oscilloscope (100 MHz) with built-in 2-channel signal generator. This compact lightweight digital oscilloscope provides exceptionally accurate waveform viewing and measurements. RIGOL DS2102A-S provides up to 50 000 wfms/s waveform acquisition rate.

RIGOL DS2102A-S digital oscilloscope is ideal for production tests, field service, research, design and all other applications involving analog/digital circuit tests and troubleshooting, as well as education and training.

Features

  • Bandwidth: 100 MHz.
  • 2 channels.
  • Real-time sample rate: 2 GSa/s.
  • Memory depth: 14 Mpts.
  • Built-in 2-channel signal generator.
  • Innovative UltraVision technology.
  • Vertical sensitivity: 500 μV/div – 10 V/div.
  • Waveform acquisition rate up to 50,000 wfms/s.
  • Math functions: Add, Subtract, Multiply, FFT.
  • 8-inch color LCD.
  • Standard interface: USB host & device, LAN, AUX.
  • The recommended calibration interval period is one year.
  • Real-time waveform recording, waveform playback, and waveform analysis.
  • Compact design, small dimensions, light weight.

Technical Specifications

Bandwidth 100 MHz
Channels 2
Real time sample rate 2 GSa/s (single-channel), 1 GSa/s (dual-channel)
Memory depth 14 Mpts (Std.), 56 Mpts (Opt.)
Waveform acquisition rate 50,000 wfms/s (Max. )
Vertical sensitivity range 500 μV/div – 10 V/div
Offset range 500 μV/div – 50 mV/div (± 2 V)
51 mV/div – 200 mV/div (± 10 V)
205 mV/div – 2 V/div (± 50 V)
2.05 V/div – 10 V/div (± 100 V)
Vertical resolution 8 bits
Math Add, Subtract, Multiply, FFT, editable
Output voltage ~ 3 V, peak-peak
Frequency 1 kHz
General Specifications
Trigger modes Auto, Normal, Single
Power 50 W (max.)
Power voltage 100-240 V, 45-440 Hz
Temperature range Operation: 0°C to +50°C
Non-operation: -20°C to +70°C
Cooling method Fan
Standard Ports USB host (support USB-GPIB), USB device, LAN, Aux (TrigOut/PassFail)
Display 8" WVGA color LCD (800×480)
Weight 3.9 kg (± 0.2 kg)
Dimensions 361.6 × 179.6 × 130.8 mm

Video

Youtube video

You'll find even more video reviews in the Video tab. Go and check it out!

Package Contents

  • RIGOL DS2102A-S digital oscilloscope (1 pc.)
  • Passive probes (2 pcs.)
  • Power cable (1 pc.)
  • USB data cable (1 pc.)
Specifications
Number of channels
  • dual-channel
Bandwidth
  • 100 MHz
Type
  • desktop
  • with built-in generator
Sample Rate
  • 2 GS/s
Screen Size
  • 8,0" TFT LCD
Storage Capacity
  • 14 MB
Video
Youtube video
Youtube video
Youtube video
Youtube video
