Handheld Digital Oscilloscope Micsig MS220T

id: 856585
110, 220 V Warranty: 12 month (s)
2 channel handheld multifunctional oscilloscope (200 MHz bandwidth) with multimeter function and a 5.7" TFT LCD touch screen.
Price coming soon
Contact
sales team
Price coming soon
Contact
sales team
Add to wishlist
Compare
Compare
Impossible to estimate the shipping cost
Overview
Specifications
Substitution
Video
Delivery
Payment
Warranty
Overview

Micsig MS220T allows moving the waveform and zooming in and out in three ways: using the buttons, using the scroll wheel or using touch screen. The Micsig software, ScopeSuite, has functions including updating, real time control, measurement, storage, dynamic display, record and data analysis. The MS220T has a 5.7" TFT LCD touch screen with 640×480 resolution.

Features

  • 3 control modes: touch, button, scroll wheel
  • 240Kpts memory depth
  • 640*480 screen resolution
  • 31 auto measurements
  • Cursor measurements
  • 3 record modes: multimeter, oscilloscope, and oscilloscope waveform
  • multimeter is capable of conducting 10 measurements and tests such as AC/DC voltage, current, resistance, etc.
  • ScopeSuite software

Technical Specifications

Bandwidth 200 MHz
Rise Time ≤1.5 ns
Real time sampling rate single channel: 1 GSa/s
dual channels: 500 MSa/s
Memory depth single channel: 240 Kpts
dual channels: 120 Kpts
Isolated channel not supported
Vertical system
Channels 2 oscilloscope channels, 1 multimeter channel
Coupling modes DC, AC, GND
Input impedance parallel 1 MΩ ±1% with 15 pF ±3 pF
Vertical scale 5 mV/div ~ 50 V/div
Vertical resolution 8 bits
Max. voltage input 600V CAT Ⅱ 300V CAT Ⅲ
Horizontal system
Timebase 4 ns/div ~ 10 s/div
Timebase accuracy 20 ppm
Sample mode normal, average, pk-pk, envelope
Waveform storage 4 ref waveforms (can be upgraded to flash disk storage)
Trigger system
Trigger types edge, pulse, logic, serial bus (UART, LIN, CAN, SPI, I2C)
Trigger coupling DC, AC, High-frequency suppression, Low-frequency suppression, Noise suppression
Trigger modes auto, normal, single
Trigger source CH1, CH2
Measurement
Automatic measurements 31 types
Cursor types horizontal cursor, vertical cursor, cross cursor
Math
Operator + , - , × , /
FFT window settings Rectangular, Hamming, Blackman-Harris, Hanning
Display Features
Screen 5.7 inch TFT LCD touch screen
Resolution 640 × 480
3D waveform display not supported
Grid of waveform display zone horizontal 12 divs × vertical 8 divs
Form YT form (can be upgraded to XY form)
I/O Port
Mini USB 2.0 connection to PC
USB 2.0 connection to flash disk
WiFi not supported
Multimeter
Measurement types 10 physical measurements such as voltage, current, resistance, capacitance, diode , etc
Measurement accuracy 4 bits
Measurement display max, average, min, values with time stamp, relative measurement
Data Logger
Logger content multimeter measurements, oscilloscope waveform, oscilloscope measurements
Logger timebase multimeter measurements: 10s/div ~ 20min/div
oscilloscope measurements: 10s/div ~ 20min/div
oscilloscope waveform 100us/div ~ 2min/div
Logger time length max 17 days (can be upgraded to flash disk record)
Power Supply
Power adapter input: 100-240 V AC, 50-60 Hz, 2 A;
output: 12 V DC, 5 A
Battery capacity: 7.4 V / 6000 mAh,
work time: 4~5 hours
Environment
Operation temperature -20℃ ~ +50℃
Operation humidity < 85% RH
Mechanical Parameters
Dimensions 254 × 160 × 60 mm
Weight Oscilloscope: 1380 g (no battery),
accessories (standard): 691 g,
battery (standard): 276 g

Video

Youtube video

Package Contents

  • Micsig MS220T Handheld Digital Oscilloscope — 1 pc.
  • Power Adapter — 1 pc.
  • 10x Oscilloscope Probe — 1 set
  • Multimeter Probe — 1 set
  • USB Cable — 1 pc.
  • Li-ion Battery — 1 pc.
  • CD / ScopeSuite Software — 1 pc.
