Handheld Digital Oscilloscope UNI-T UTD1025CL

id: 834638
Handheld Digital Oscilloscope UNI-T UTD1025CL
Overview
Description
Specifications
Video
Delivery
Payment
Warranty
USD 271.70
Notify
when in stock
Overview
2.3 kg 110, 220 V Warranty: 24 months
Single channel lightweight, handheld oscilloscope with 25 MHz bandwidth, 200 MS/s sample rate and a set of multimeter measurement functions.
USD 271.70
Notify
when in stock
Add to wishlist
Compare
Compare
USD 271.70
Notify
when in stock
Impossible to estimate the shipping cost

You may also like

Handheld Digital Oscilloscope OWON HDS1022M N
Add to wishlist
Handheld Digital Oscilloscope OWON HDS1022M-N
USD 490.00
Add to wishlist
Add to cart
Dual-channel lightweight handheld oscilloscope with 20 MHz bandwidth, 100 MS/s sample rate and a set of multimeter measurement functions.
Availability in stock: HK
Shipping cost
ID: 856642 3 kg 110, 220
Handheld Digital Oscilloscope SIGLENT SHS810
Handheld Digital Oscilloscope SIGLENT SHS810
USD 573.00
USD 515.70
Add to cart
100 MHz bandwidth model of the SHS800 series of devices, with 2 channels and three main functions such as oscilloscope, multimeter and waveform recorder.
Shipping cost
ID: 837024 8 kg 110, 220
Description

UNI-T UTD1025CL is a single channel lightweight, handheld oscilloscope with 25 MHz bandwidth and 200 MS/s sample rate. UNI-T UTD1025CL handheld digital oscilloscope also performs multimeter measuring functions: AC/DC voltage and current, resistance, capacity, diode and continuity tests.

Soft

Download UNI-T UTD1025CL software.

Features

  • 3.5-inch color LCD (320 × 240)
  • Trigger types: Edge, Pulse, Video, Alternate
  • Multimeter functions:
    • DC voltage and current
    • AC voltage and current
    • Resistance
    • Capacitance
    • Continuity check
    • Diode test

Technical Specifications

Bandwidth 25 MHz
Rise time ≤ 14 ns
Real-time sampling rate 200 MS/s
Vertical sensitivity 5 mV/div ~ 20 V/div
Record length (max) 12 kpts
Scanning speed 10 ns ~ 50 s/div
Trigger type Edge, Pulse, Video and Alternate
Multimeter
DC voltage 400 mV / 4 V / 40 V / 400 V: ±(1%+5)
AC voltage 400 mV / 4 V / 40 V / 400 V: ±(1.2%+5)
DC current 400 μA / 4000 μA / 40 mA / 4000 mA / 10 A: ±(1.5%+5)
AC current 400 μA / 4000 μA / 40 mA / 4000 mA / 10A: ±(5%+5)
Resistance 400 Ω / 4 KΩ / 40 KΩ / 400 KΩ / 4 MΩ / 40 MΩ: ±(1.5%+5)
Capacitance 51.2 nF / 512 nF / 5.12 μF / 51.2 μF / 100 μF: ±(3%+5)
General characteristics
Max.display 4000
LCD size 3.5"
Power power supply 220 V, 50 Hz
battery 7.4 V, 3600 mAh
Dimensions 199 × 118 × 49 mm
Weight 0.9 kg

Video

Youtube video

Package Contents

  • UNI-T UTD1025CL digital oscilloscope module (1 pc.)
  • Oscilloscope probe (1:1, 10:1) (1 pc.)
  • Test lead 10 A (1 pair.)
  • Power adaptor (1 pc.)
  • Carrying case (1 pc.)
  • USB cable (1 pc.)
  • Software CD (1 pc.)
  • User manual (1 pc.)
Read more
Description

UNI-T UTD1025CL is a single channel lightweight, handheld oscilloscope with 25 MHz bandwidth and 200 MS/s sample rate. UNI-T UTD1025CL handheld digital oscilloscope also performs multimeter measuring functions: AC/DC voltage and current, resistance, capacity, diode and continuity tests.

Soft

Download UNI-T UTD1025CL software.

Features

  • 3.5-inch color LCD (320 × 240)
  • Trigger types: Edge, Pulse, Video, Alternate
  • Multimeter functions:
    • DC voltage and current
    • AC voltage and current
    • Resistance
    • Capacitance
    • Continuity check
    • Diode test

Technical Specifications

Bandwidth 25 MHz
Rise time ≤ 14 ns
Real-time sampling rate 200 MS/s
Vertical sensitivity 5 mV/div ~ 20 V/div
Record length (max) 12 kpts
Scanning speed 10 ns ~ 50 s/div
Trigger type Edge, Pulse, Video and Alternate
Multimeter
DC voltage 400 mV / 4 V / 40 V / 400 V: ±(1%+5)
AC voltage 400 mV / 4 V / 40 V / 400 V: ±(1.2%+5)
DC current 400 μA / 4000 μA / 40 mA / 4000 mA / 10 A: ±(1.5%+5)
AC current 400 μA / 4000 μA / 40 mA / 4000 mA / 10A: ±(5%+5)
Resistance 400 Ω / 4 KΩ / 40 KΩ / 400 KΩ / 4 MΩ / 40 MΩ: ±(1.5%+5)
Capacitance 51.2 nF / 512 nF / 5.12 μF / 51.2 μF / 100 μF: ±(3%+5)
General characteristics
Max.display 4000
LCD size 3.5"
Power power supply 220 V, 50 Hz
battery 7.4 V, 3600 mAh
Dimensions 199 × 118 × 49 mm
Weight 0.9 kg

Video

Youtube video

Package Contents

  • UNI-T UTD1025CL digital oscilloscope module (1 pc.)
  • Oscilloscope probe (1:1, 10:1) (1 pc.)
  • Test lead 10 A (1 pair.)
  • Power adaptor (1 pc.)
  • Carrying case (1 pc.)
  • USB cable (1 pc.)
  • Software CD (1 pc.)
  • User manual (1 pc.)
Specifications
Number of channels
  • single-channel
Bandwidth
  • 25 MHz
Type
  • portable
  • multimeter
Sample Rate
  • 200 MSa/s
Storage Capacity
  • 12 KB
Screen Size
  • 3.5" TFT LCD
Video
Youtube video
