Hot Air Repairing System AOYUE 738

id: 7102
Hot Air Repairing System AOYUE 738
Overview
Description
Specifications
Delivery
Payment
Warranty
USD 172.00
Contact
sales team
Overview
5.9 kg 220 V Warranty: 12 months
Repairing System AOYUE 738 - three in one environment friendly repairing system that combines the functions of a Hot Air Gun, a Soldering Iron and a Smoke Absorber
USD 172.00
Contact
sales team
Compare
Compare
USD 172.00
Contact
sales team
Impossible to estimate the shipping cost

You may also like

Hot Air Rework Station Accta 301
Add to wishlist
Hot Air Rework Station Accta 301
USD 129.00
Add to wishlist
Add to cart
Compact design, temperature display, hot air gun auto switch-off, 50 W soldering iron, 350 W hot air gun, soldering iron and hot air gun temperature range: 80-480°C.
Made in Ukraine
Availability in stock: HK
Shipping cost
ID: 4060 3.2 kg 220
Description

Features

  • Microprocessor-controlled ESD safe unit.
  • All digital display of hot air temperature, soldering iron temperature and air pressure with touch type panel controls.
  • Three in one environment friendly repairing system that combines the functions of a Hot Air Gun, a Soldering Iron and a Smoke Absorber.
  • Unique 15-minute stand-by auto sleep mode. Returns to previous setting when the handle is held up again.
  • Designed with an auto-cool off process. Upon turning the unit off, it starts to blow cold air until it reaches a safe temperature of 85 degrees, this is to ensure safety and to prolong usage life of the heating element.
  • Creative built-in smoke extractor that absorbs the fumes created at the source. Eliminates the space hindering smoke absorbing units yet allowing a healthy environment.
  • Compatible with various type of air nozzles.
  • Compatible with different kind of tips.

Technical specifications

Main Unit
Voltage 220 V
Power consumption 600 W (max.)
Dimensions 188 × 126 × 250 mm
Soldering Iron
Heating element voltage 24 V AC
Heating element power 45 W
Heating element ceramic
Temperature range 250...480 °C
Hot Air Gun
Heating element power 500 W
Heating element ceramic + thermocouple
Temperature range 100...480 °C
Timer 20...9999 sec.
Pump type diaphragm
Air capacity 23 l/min.
Smoke Absorber
Vacuum pressure 600 mm Hg

Compatible Soldering Tips

Read more
Description

Features

  • Microprocessor-controlled ESD safe unit.
  • All digital display of hot air temperature, soldering iron temperature and air pressure with touch type panel controls.
  • Three in one environment friendly repairing system that combines the functions of a Hot Air Gun, a Soldering Iron and a Smoke Absorber.
  • Unique 15-minute stand-by auto sleep mode. Returns to previous setting when the handle is held up again.
  • Designed with an auto-cool off process. Upon turning the unit off, it starts to blow cold air until it reaches a safe temperature of 85 degrees, this is to ensure safety and to prolong usage life of the heating element.
  • Creative built-in smoke extractor that absorbs the fumes created at the source. Eliminates the space hindering smoke absorbing units yet allowing a healthy environment.
  • Compatible with various type of air nozzles.
  • Compatible with different kind of tips.

Technical specifications

Main Unit
Voltage 220 V
Power consumption 600 W (max.)
Dimensions 188 × 126 × 250 mm
Soldering Iron
Heating element voltage 24 V AC
Heating element power 45 W
Heating element ceramic
Temperature range 250...480 °C
Hot Air Gun
Heating element power 500 W
Heating element ceramic + thermocouple
Temperature range 100...480 °C
Timer 20...9999 sec.
Pump type diaphragm
Air capacity 23 l/min.
Smoke Absorber
Vacuum pressure 600 mm Hg

Compatible Soldering Tips

Specifications
Pump type
  • compressor
Design type
  • Desktop
Vacuum pick-up tool
  • Non-available
Desoldering Pump
  • Available
Power Supply
  • Non-available
Soldering Iron Power
  • 45 W
Hot Air Gun Power
  • 500 W
Desoldering Gun
  • Non-available
