Infrared Thermometer UNI-T UT302A
id: 860184
Infrared Thermometer UNI-T UT302A
Overview
Description
Specifications
Delivery
Payment
Warranty
Discontinued
Overview
0.52 kg Warranty: 24 months
Infrared pyrometer for surface temperature measurements within the range from –32ºC to 450ºC. Data Hold, Max/Min/Dif/Avg, ºC/ºF selection. Read more
Discontinued
Description
UNI-T UT302A infrared thermometer for non-contact temperature measurements is fast, efficient and easy to use when checking starters, fuses, enclosed relays, bearings, belts and sheaves. IR pyrometer is capable of measuring temperatures from –32 °C to 450 °C.
This infrared ihermometer is NOT a medical device. However, you can use it to measure a person’s body temperature. To do this, you need to select empirically and set the emission factor in the settings (it's in the range 0.6-0.9 for the human body).
You should always maintain safety and security while working:
- make sure the laser beam don't get into your eyes;
- don't let children play with the device;
- don't use the device near surfaces that could reflect the laser beam into anyone's eyes.
Features
- Temperature range –32 ºC ~ 450 ºC.
- Electricity cut off memory.
- Laser switch.
- Search option.
- Temperature Data Hold function.
- ºC/ºF selection.
- Max/Min measurements.
- Dif/Avg measurements.
- Tripod mount.
- Sleep mode.
- Low battery indication.
Technical Specifications
| Display | LCD with backlight, 32 × 29 mm | |
| Temperature | range | –32 ºC ~ 450 ºC |
| accuracy | ±1.8ºC or ±1.8% | |
| resolution | 0.1 | |
| Repeatability | ±0.5˚C or ±0.5% | |
| Distance to spot size | 20:1 | |
| Laser power | wavelength 630-670 nm | |
| Power | USB or 9 V battery (6F22) | |
| Dimensions (H × W × D) | 169 × 138 × 53 mm | |
| Weight | 270 g | |
Package Contents
- Thermometer UNI-T UT302A — 1 pc.
- USB cable — 1 pc.
- Manual — 1 pc.
Note! Batteries are not included in the package.
Specifications
| Min. temperature |
|
| Optical resolution |
|
| Regulated compensation factor |
|
| Max. temperature |
|
