LC/APC Fiber Optic Connector, 10 pcs/pack

id: 908986
LC/APC Fiber Optic Connector, 10 pcs/pack
Overview
Description
Delivery
Payment
Warranty
USD 17.70
Add to cart
Overview
0.1 kg
Availability in stock: HK
Green optical LC/APC connector with the end face grounded into an 8° bevel. Used for indoor cross-connects where a high density of optical ports is required.
USD 17.70
Add to cart
Add to wishlist
Compare
Compare
USD 17.70
Add to cart
Impossible to estimate the shipping cost
Description

LC/APC green fiber optic connectors are used in optical SFP transceivers, some network equipment, and in distribution panels where a high density of optical ports is required. LC connectors are a smaller version of SC connectors.

The connector ferrule is beveled at an angle of 8-9°, which makes the fiber end face tighter, and reflects light through its bevel angle to the cladding instead of returning directly to the light source, providing better connection performance.

The connector is made of plastic and has a locking latch, which is used in modular connectors of copper cable systems (RJ-45 locking system). The diameter of the connector's ferrule is 1.25 mm. The LC/APC connector guarantees a fast, high-quality, and reliable connection.

Features

Read more
Description

LC/APC green fiber optic connectors are used in optical SFP transceivers, some network equipment, and in distribution panels where a high density of optical ports is required. LC connectors are a smaller version of SC connectors.

The connector ferrule is beveled at an angle of 8-9°, which makes the fiber end face tighter, and reflects light through its bevel angle to the cladding instead of returning directly to the light source, providing better connection performance.

The connector is made of plastic and has a locking latch, which is used in modular connectors of copper cable systems (RJ-45 locking system). The diameter of the connector's ferrule is 1.25 mm. The LC/APC connector guarantees a fast, high-quality, and reliable connection.

Features

  • Supplied in a blister pack (10 pieces per pack).
  • Fast and reliable installation, easy operation, multiple uses.
  • Compact, durable, and lightweight.

Technical Specifications

Type LC/APC
Fiber Mode 9/125 μm, singlemode
Cable Diameters 0.9/2.0/3.0 mm
Ferrule ceramic, beveled
Coating Diameter 250 μm and 900 μm
Operation Time about 15 s (exclude fiber presetting)
Insertion Loss ≤ 0.3 dB (1310 nm and 1550 nm)
Return Loss ≤ 50 dB
Reusable Times >5 times
Tension Test ≥100 N
Operating Temperature -40°C~+85°C
Number per pack 10 pcs.

Package Contents

  • LC/APC Fiber Optic Connector (green) — 10 pcs.
