Mixed Signal Oscilloscope RIGOL MSO4032

id: 844227
8 kg 110, 220 V Warranty: 36 month (s)
Dual-channel mixed signal oscilloscope with 350 MHz bandwidth, up to 4 GSa/s real-time sample rate, 16-channel Logic Analyzer, 9" display and up to 110,000 waveforms/sec capture rate.
USD 5599.00
Contact
sales team
USD 5599.00
Contact
sales team
Add to wishlist
Compare
Compare
Impossible to estimate the shipping cost
Overview
Specifications
Delivery
Payment
Warranty
Overview

RIGOL MSO4032 is the new dual-channel mixed signal oscilloscope (350 MHz) with 16-channel Logic Analyzer. RIGOL MSO4032 provides up to 110,000 wfms/s waveform acquisition rate.

RIGOL MSO4032 digital oscilloscope is perfect for production tests, field service, research, design and all other applications involving analog/digital circuit tests and troubleshooting, as well as education and training.

Features

  • Bandwidth: 350 MHz.
  • 2 channels + 16 for Logic Analyzer.
  • Real-time sample rate: analog channel up to 4 GSa/s, digital channel up to 1 GSa/s.
  • Memory depth: analog channel up to 140 Mpts, digital channel up to 28 Mpts.
  • Innovative UltraVision technology.
  • Waveform acquisition rate up to 110,000 wfms/s.
  • Low noise floor, min. vertical sensitivity is 1 mV/div
  • A variety of Trigger functions
  • Real time waveform record, replay and analysis
  • 9-inch color LCD.
  • Standard interface: LAN, USB host and device, AUX, VGA, USB-GPIB (opt.)

Technical Specifications

Bandwidth 350 MHz
Channels 2 + 16
Real time sample rate Analog: max. 4 GSa/s single channel, 2 GSa/s dual channel
Digital: max. 1 GSa/s per channel
Memory depth Analog: up to 140 Mpts single channel, 70 Mpts dual channel
Digital: up to 28 Mpts per channel
Waveform acquisition rate up to 110,000 wfms/s
Real time waveform record, replay and analysis Analog: up to 200,000 frames
Digital: up to 64,000 frames
Vertical sensitivity range 1 mV/div to 5 V/div (1 MΩ)
1 mV/div to 1 V/div (50 Ω)
Offset range 1 mV/div to 124 mV/div: ± 1.2 V (50 Ω)
126 mV/div to 1 V/div: ± 12 V (50 Ω)
1 mV/div to 225 mV/div: ± 2 V (1M Ω)
230 mV/div to 5 V/div: ± 40 V (1M Ω)
Vertical resolution 8 bit (analog)
Math Add, Subtract, Multiply, Divide, FFT, editable, logic operations
Output voltage ~ 3 V, peak-peak
Frequency 1 kHz
General Specifications
Power 120 W (max.)
Power voltage 100-240 V, 45-440 Hz
Cooling method Fan
Display 9" color LCD (800×480)
Weight 4.8 kg (± 0.2 kg)
Dimensions 440.0 × 218.0 × 130.0 mm

Additional Information

Download RIGOL MSO4032 Data Sheet.

Download RIGOL MSO4032 User Guide.

Video

Youtube video

Youtube video

Youtube video

Youtube video

Package Contents

  • RIGOL MSO4032 digital oscilloscope (1 pc.)
  • Passive probes (2 pcs.)
  • Power cable (1 pc.)
  • USB data cable (1 pc.)
  • Front cover (1 pc.)
Specifications
Number of channels
  • dual-channel
  • with 16 channel logic analyzer
Type
  • desktop
  • mixed-signal
Storage Capacity
  • 140 MB
Sample Rate
  • 4 GSa/s
Bandwidth
  • 350 MHz
Screen Size
  • 9,0" TFT LCD
