PON Power Meter EXFO PPM-352C
id: 857248
PON Power Meter EXFO PPM-352C
Overview
Description
Delivery
Payment
Warranty
USD 798.56
Overview
Bestseller
Made in Canada
3 kg
Availability in stock:
HK
Warranty: 12 months Complex Device, Tailored Solutions: We're Here to Help!
This device is highly sophisticated. If needed, we're ready to assist you in finding the best model for your specific needs.
PPM-350C series optical power meter for PON, BPON, GPON, EPON, FTTx networks. Read more
USD 798.56
Note! This item is shipped within 10 working days.
Description
EXFO PPM-352C is a PPM-350C series optical power meter for PON, BPON, GPON, EPON, FTTx networks.
Features
- Simultaneous measurement of all PON signals, anywhere on the network
- Innovative workflow management, for boosted test routine efficiency
- Enhanced rugged and weatherproof design
- Protected data format, for guaranteed test result authenticity
- Two-port pass-through: all wavelengths
- Downstream OLT signal (1490 nm)
- Downstream RF video signal (1550 nm)
- Upstream BPON ONT signal for up to 622 Mbit/s, as per ITU 983 (A, B, C)
- Upstream EPON and GPON ONT signal for up to 1.25 Gbit/s, as per ITU 984 and IEEE 802.3ah
Technical Specifications
| Function | PPM-352C | PPM-353C | FTTx MODE |
|---|---|---|---|
| Power measurement range—pass zone for continuous data stream | 1310 nm | 8 to –40 dBm | 8 to –40 dBm |
| 1490 nm | 12 to –40 dBm | 12 to –40 dBm | |
| 1550 nm | 25 to –40 dBm | N/A | |
| Burst measurement capability | CO to ONT | CO to ONT | |
| Burst measurement range | 1310 nm | 8 to –30 dBm | 8 to –30 dBm |
| ORL | 1550 nm | 55 dB | 55 dB |
| Pass-through insertion loss | 1.5 dB | 1.5 dB | |
| Spectral passband | 1310 nm | 1260 to 1360 nm | 1260 to 1360 nm |
| 1490 nm | 1480 to 1500 nm | 1480 to 1500 nm | |
| 1550 nm | 1539 to 1565 nm | 1539 to 1565 nm | |
| Power uncertainty | 0.5 dB | 0.5 dB | |
| Calibrated wavelengths | 1310/1490/1550 nm | 1310/1490 nm | |
| Threshold sets | 10 configurable threshold sets with threshold naming |
||
| OPM MODE (BROADBAND CW) | |||
| Power measurement range | 1310 nm | 25 to –40 dBm | |
| 1490 nm | 25 to –40 dBm | ||
| 1550 nm | 25 to –40 dBm | ||
| ORL | 1550 nm | 55 dB | |
| Power uncertainty | 0.5 dB | ||
| Calibrated wavelengths | 1310/1490/1550 nm | ||
| General Specifications | |||
| Temperature | Operating | –10 °C to 50 °C (14 °F to 122 °F) | |
| Storage | –40 °C to 70 °C (–40 °F to 158 °F) | ||
| Relative humidity | 0 % to 95 % non-condensing | ||
| Autonomy | FTTx mode (burst) | 35 hours | |
| OPM mode (CW) | 80 hours | ||
| Number of ports | 2 | ||
| Recommended calibration interval | 3 years | ||
| Size (H x W x D) | 195 × 100 × 57 mm | ||
| Weight | 0.4 kg (0.9 lb) | ||
Package Contents
- EXFO PPM-352C Optical Power Meter – 1 pc.
- USB cable – 1 pc.
- Wrist strap – 1 pc.
- Protective cover for optical ports – 1 pc.
- Quick reference guide – 1 pc.
- CD with software and user guide – 1 pc.
