Soldering Iron CXG RD70W
id: 895812
Soldering Iron CXG RD70W
Overview
Description
Specifications
Video
Delivery
Payment
Warranty
Discontinued
Overview
Video
0.5 kg Warranty: 6 months
Ceramic soldering iron with continuous temperature control within 100°C and 480°C. Power 70 W. Read more
Discontinued
Description
CXG RD70W is a ceramic soldering iron with continuous temperature control within 100°C and 480°C. The soldering iron is equipped with a 900M-T-B noncombustible tip, a rubberized handle, and a 1.5 m power cord.
Features
- Continuous temperature control with a simple and reliable controller.
- Heating LED indicator.
- Fast heating, which makes the flux near the tip evaporate slower. Also, it helps the component doesn't overheat while soldering.
- Tip-to-ground resistance is less than 2 Ω.
Technical Specifications
| Power | 70 W |
| Input voltage | AC 220 V 50 Hz |
| Output temperature | 100°C - 480°C |
| Temperature stability | ±5°C (without load) |
| Heating element | ceramic heater A1326 |
| Heating time | 8 s |
| Tip type | 900M-T-B |
| Tip holder | GP4 |
| Sleep mode | no |
| Tip-to-ground resistance | <2 Ω |
| Tip-to-ground potential | <2 mV |
| Cord length | 1.5 m |
| Body dimensions | 150 × 20 × 20 mm |
| Weight | 300 g |
Video
Package Contents
- Soldering Iron CXG RD70W — 1 pc.
- User Manual — 1 pc.
Specifications
| Power Consumption |
|
| Power Supply |
|
| Temperature stabilization |
|
| Controls |
|
