USB Interfaced Universal Programmer Xeltek X1

id: 886273
3 kg Warranty: 6 month (s)
Ultra-high speed standalone USB3.0 universal programmer. Ensures programming up to four chips simultaneously.
Price coming soon
Contact
sales team
Price coming soon
Contact
sales team
Add to wishlist
Compare
Compare
Impossible to estimate the shipping cost
Overview
Delivery
Payment
Warranty
Overview

Xeltek X1 is a universal USB interfaced programmer used for programming EPRO, Paged EPROM, Parallel and Serial EEPROM, FPGA, PROM, FLASH(NOR & NAND), BPROM, NVRAM, SPLD, CPLD, EPLD, Firmware HUB, Microcontroller, MCU.

Features

  • Built with 48 universal and 96 high-speed pin-drivers.
  • Ensures programming up to four chips simultaneously.
  • Safety mechanisms: self-calibration, self-diagnosis, wrong chip placement detection, ID checking, over-current, and over-voltage protection, etc.
  • Connected to PC via USB 3.0.
  • Programming algorithms used for high reliability.
  • Production mode starts chip operation at the moment the chip is inserted in the socket properly.
  • Password can be set for project files.
  • Dynamic buffer makes it possible that each chip is programmed with a different data file.
  • Batch command combines device operations like program, verify, security into a single command at any sequence.
  • Log file and statistic table for quality tracking.
  • Project function simplifies processes such as device selection, file load, device configuration setting, program option, and batch file setting into one touch step.
  • JAM/STAPL Player and Direct C supported.
  • Windows 7, Windows 8, Windows 10 compatibility.

Application

  • Device repair: re-flashing microchips, microcontrollers.
  • Flashing new microchips.
  • Serial manufacturing: microchips, microcontrollers programming.
  • Restoring data from microchips of solid-state drives like memory cards, USB flash drives.

Technical Specifications

Programmable devices EPRO, Paged EPROM, Parallel and Serial EEPROM, FPGA, PROM, FLASH(NOR & NAND), BPROM, NVRAM, SPLD, CPLD, EPLD, Firmware HUB, Microcontroller, MCU
Package types supported
DIP, SDIP, PLCC, JLCC, PGA, LGA, SOIC, SOJ, SOT, QFP, TQFP, PQFP, VQFP, MQFP, LQFP, TSOP, SOP, TSOPII, PSOP, SSOP, TSSOP, SON, EBGA, FBGA, FTBGA, VFBGA, μBGA, CSP, SCSP, QFN, HVQFN
PC interface USB 3.0
Power AC input: from 100 V to 240 V, 50/60 Hz; DC output: 12 V / 1,5 A
Dimensions device: 195 × 125 × 48 mm
package: 310 × 250 × 145 mm
Weight device: 0.6 kg
package: 1.2 kg

Package Contents

  • USB Interfaced Universal Programmer Xeltek X1 — 1 pc.
  • AC Adapter — 1 pc.
  • USB Cable — 1 pc.
  • Software CD — 1 pc.
