Digital Multimeter Rigol DM3051
Overview
Description
Specifications
Delivery
Payment
Warranty
Discontinued
Contact
sales team
Overview
2.7 kg 110, 220 V Warranty: 36 months
26 measurement functions: DC/AC voltage and current, 2- and 4-wire resistance, capacitance, continuity test, frequency, temperature, etc. Resolution: 5¾ digits.
Discontinued
Contact
sales team
Compare
Compare
Discontinued
Contact
sales team
Impossible to estimate the shipping cost
Description

Digital multimeter with 5¾ resolution for measuring DC/AC voltage and current, 2-wire and 4-wire resistance, capacitance, frequency, period, temperature, and so on

Rigol DM3051 Digital Multimeter Features

  • Resolution: 5¾ digits and 480,000 Count
  • 50 K/s maximum sample rate
  • 26 measurement functions:
    • DC/AC voltage and current, 2-wire and 4-wire resistance, capacitance, continuity test, diode test, frequency, period, ratio test, temperature, and so on
    • Upper limit and lower limit on threshold measurement
    • Arithmetic: maximum, minimum, limit, average, dBm, dB
    • Data acquisition functions: data records, inspection, automatic measurement
  • 256 x 64 pixel monochrome LCD
  • Built in Storage: Store up to 10 setup configurations,10 Data records and 10 sensor setups
  • Simple, convenient, flexible control software: Ultralogger, Ultrasensor and UltraDMM Supports for Microsoft® Windows 98/Me/2000/XP
  • Approval: CAT II 300V and CAT I 1000V. Pollution Degree 1.
  • Size (H x W x D): 107 x 232 x 91 mm
  • Weight: 2.5kg

Video

Youtube video

You'll find even more video reviews in the Video tab. Go and check it out!

Rigol DM3051 Digital Multimeter Comparative Specifications

Model DM3051 DM3052 DM3054 DM3058 DM3061 DM3062 DM3064
Resolution 5 ¾ 5 ½ 6 ½
Configuration N.A. LAN/GPIB LAN/GPIB and Multiplexer Module LXI/GPIB N.A. LAN/GPIB LAN/GPIB and Multiplexer Module
Maximum Sample Rate 50 K/s 120 K/s 50 K/s

Rigol DM3051 Digital Multimeter Technical Specifications

Range Resolution Accuracy 1
DC Voltage 400 mV 100 nV 0.025+0.008
4 V 1 µV 0.025+0.006
40 V 10 µV
400 V 100 µV 0.030+0.006
1000 V 1 mV 0.030+0.005
DC Current 2 mA 10 nA 0.050+0.070
20 mA 100 nA 0.050+0.008
200 mA 1 µA 0.050+0.009
1 A 10 µA 0.100+0.070
10 A 100 µA 0.200+0.007
4-wire Resistance (or 2–wire using Math Null) 400 Ω 100 µΩ 0.050+0.010
4 kΩ 1 mΩ 0.015+0.006
40 kΩ 10 mΩ
400 kΩ 100 mΩ 0.030+0.007
4 MΩ 1 Ω 0.060+0.010
100 MΩ 100 Ω 2.00+0.005
Diode Test 2.4 V Range fixed at 2 VDC 0.05+0.010
Continuity 2 kΩ Range fixed at 2 kΩ 0.05+0.010
Capacitance 4 nF 0,1 pF 2+2.5
40 nF 1 pF 1+0.5
400 nF 10 pF
4 µF 100 pF
40 µF 1 nF
200 µF 10 nF
Range Frequency Range Accuracy 1
AC Voltage (RMS) 200 mV 10-45Hz 1.0+0.1
45Hz-20kHz 0.2+0.1
20-50kHz 2.0+0.2
50-100kHz 4.0+0.2
2V, 20V, 200V, 750V 10-45Hz 1.0+0.1
45Hz-20kHz 0.2+0.1
20-50kHz 1.0+0.1
50-100kHz 2.0+0.2
AC Current (RMS) 20 mA, 200 mA 10 - 45 Hz 1.5+0.1
45 Hz - 2k Hz 0.5+0.1
2 - 10 kHz 2.0+0.2
1 A 10 - 45 Hz 1.5+0.5
45 Hz - 2k Hz 0.5+0.5
2 - 10 kHz 2.0+0.5
10 A 10 - 45 Hz 1.5+0.1
45 Hz - 2k Hz 0.5+0.1
2 - 5 kHz 2.0+0.2
Range Frequency Range Accuracy 2
Frequency
Period
200mV, 2V, 20V, 200V, 750V 3 - 5 Hz 0.10
5 - 10 Hz 0.07
10 - 40 Hz 0.02
40 Hz - 300 kHz
20mA, 200mA, 1A, 10A 3 - 5 Hz
0.10
5 - 10 Hz 0.07
10 Hz - 10 kHz 0.02

1Accuracy (% of reading + % of range) is specified for a period of one year after calibration and at 23°C±5°C.
2Accuracy (% of reading) is specified for a period of one year after calibration and at 23°C±5°C.

Rigol DM3051 Digital Multimeter Package contains

  • Power cord
  • USB data cable
  • Two test leads (black and red)
  • User manual
  • A CD-ROM
    • User guide
    • UltraSensor PC software
    • UltraLogger PC software

Rigol DM3051 Digital Multimeter Applications

  • Experimental project test
  • Electronic signal monitor and control
  • Support user-defined sensors test platform
  • Support high-speed/high-resolution data acquisition system
  • Calibrator for low accuracy DMM
  • Aging test
Read more
Description

Digital multimeter with 5¾ resolution for measuring DC/AC voltage and current, 2-wire and 4-wire resistance, capacitance, frequency, period, temperature, and so on

Rigol DM3051 Digital Multimeter Features

  • Resolution: 5¾ digits and 480,000 Count
  • 50 K/s maximum sample rate
  • 26 measurement functions:
    • DC/AC voltage and current, 2-wire and 4-wire resistance, capacitance, continuity test, diode test, frequency, period, ratio test, temperature, and so on
    • Upper limit and lower limit on threshold measurement
    • Arithmetic: maximum, minimum, limit, average, dBm, dB
    • Data acquisition functions: data records, inspection, automatic measurement
  • 256 x 64 pixel monochrome LCD
  • Built in Storage: Store up to 10 setup configurations,10 Data records and 10 sensor setups
  • Simple, convenient, flexible control software: Ultralogger, Ultrasensor and UltraDMM Supports for Microsoft® Windows 98/Me/2000/XP
  • Approval: CAT II 300V and CAT I 1000V. Pollution Degree 1.
  • Size (H x W x D): 107 x 232 x 91 mm
  • Weight: 2.5kg

Video

Youtube video

You'll find even more video reviews in the Video tab. Go and check it out!

Rigol DM3051 Digital Multimeter Comparative Specifications

Model DM3051 DM3052 DM3054 DM3058 DM3061 DM3062 DM3064
Resolution 5 ¾ 5 ½ 6 ½
Configuration N.A. LAN/GPIB LAN/GPIB and Multiplexer Module LXI/GPIB N.A. LAN/GPIB LAN/GPIB and Multiplexer Module
Maximum Sample Rate 50 K/s 120 K/s 50 K/s

Rigol DM3051 Digital Multimeter Technical Specifications

Range Resolution Accuracy 1
DC Voltage 400 mV 100 nV 0.025+0.008
4 V 1 µV 0.025+0.006
40 V 10 µV
400 V 100 µV 0.030+0.006
1000 V 1 mV 0.030+0.005
DC Current 2 mA 10 nA 0.050+0.070
20 mA 100 nA 0.050+0.008
200 mA 1 µA 0.050+0.009
1 A 10 µA 0.100+0.070
10 A 100 µA 0.200+0.007
4-wire Resistance (or 2–wire using Math Null) 400 Ω 100 µΩ 0.050+0.010
4 kΩ 1 mΩ 0.015+0.006
40 kΩ 10 mΩ
400 kΩ 100 mΩ 0.030+0.007
4 MΩ 1 Ω 0.060+0.010
100 MΩ 100 Ω 2.00+0.005
Diode Test 2.4 V Range fixed at 2 VDC 0.05+0.010
Continuity 2 kΩ Range fixed at 2 kΩ 0.05+0.010
Capacitance 4 nF 0,1 pF 2+2.5
40 nF 1 pF 1+0.5
400 nF 10 pF
4 µF 100 pF
40 µF 1 nF
200 µF 10 nF
Range Frequency Range Accuracy 1
AC Voltage (RMS) 200 mV 10-45Hz 1.0+0.1
45Hz-20kHz 0.2+0.1
20-50kHz 2.0+0.2
50-100kHz 4.0+0.2
2V, 20V, 200V, 750V 10-45Hz 1.0+0.1
45Hz-20kHz 0.2+0.1
20-50kHz 1.0+0.1
50-100kHz 2.0+0.2
AC Current (RMS) 20 mA, 200 mA 10 - 45 Hz 1.5+0.1
45 Hz - 2k Hz 0.5+0.1
2 - 10 kHz 2.0+0.2
1 A 10 - 45 Hz 1.5+0.5
45 Hz - 2k Hz 0.5+0.5
2 - 10 kHz 2.0+0.5
10 A 10 - 45 Hz 1.5+0.1
45 Hz - 2k Hz 0.5+0.1
2 - 5 kHz 2.0+0.2
Range Frequency Range Accuracy 2
Frequency
Period
200mV, 2V, 20V, 200V, 750V 3 - 5 Hz 0.10
5 - 10 Hz 0.07
10 - 40 Hz 0.02
40 Hz - 300 kHz
20mA, 200mA, 1A, 10A 3 - 5 Hz
0.10
5 - 10 Hz 0.07
10 Hz - 10 kHz 0.02

1Accuracy (% of reading + % of range) is specified for a period of one year after calibration and at 23°C±5°C.
2Accuracy (% of reading) is specified for a period of one year after calibration and at 23°C±5°C.

Rigol DM3051 Digital Multimeter Package contains

  • Power cord
  • USB data cable
  • Two test leads (black and red)
  • User manual
  • A CD-ROM
    • User guide
    • UltraSensor PC software
    • UltraLogger PC software

Rigol DM3051 Digital Multimeter Applications

  • Experimental project test
  • Electronic signal monitor and control
  • Support user-defined sensors test platform
  • Support high-speed/high-resolution data acquisition system
  • Calibrator for low accuracy DMM
  • Aging test
Specifications
Type
  • digital
  • desktop
Measured Values
  • DC voltage
  • AC voltage
  • AC
  • DC
  • capacitance
  • frequency
Additional Functions
  • acoustic continuity test
  • data hold
  • connection to PC (USB)
  • connection to PC (RS232)
  • automatic shutdown/sleep mode
  • RMS measurement
  • diode test
  • backlight
Range Selection
  • auto range
Digit Capacity
  • 400 000
DC Voltage
  • up to 1000 V
AC Voltage
  • up to 750 V
Capacitance
  • up to 200 μF
DC
  • up to 10 A
AC
  • up to 10 A
Inductance
  • no
Temperature
  • no
Power
  • no
Duty cycle
  • no
True RMS
  • yes
Backlight
  • yes
PC connection
  • USB
Diode test
  • yes
Analog bar graph
  • no
Transistor check
  • no
Continuity test
  • yes
Resistance
  • up to 100 MOhm
Frequency
  • up to 300 kHz
Battery Testing
  • no
