Optical Laser Source DVP-1310
id: 836855
Optical Laser Source DVP-1310
Overview
Description
Delivery
Payment
Warranty
Discontinued
Overview
0.5 kg Warranty: 12 months
Compact laser source for fiber loss testing, optical fiber network installation, testing and maintenance. Used for LAN, FDD, ATM networks, communication networks and CATV networks. Read more
Description
DVP-1310 Optical Laser Source is used for fiber loss testing, optical fiber network installation, testing and maintenance. DVP-1310 is a good choice for working with LAN, FDD, ATM networks, communication networks and CATV networks.
DVP-1310 Optical Laser Source Features
- High output power.
- Stable and reliable.
- CW or MOD output.
- MOD frequency: 270 Hz / 1 KHz / 2 KHz.
- Compact & lightweight.
- Battery power supply.
Application
- LAN, FDD, ATM networks.
- Communication networks.
- CATV networks.
DVP-1310 Optical Laser Source Technical Specifications
| Emitter type | SM LD |
| Wavelength | 1310 nm ±30 nm |
| Stability | ±0.1 dB/h |
| Output | ≥ 0 dBm |
| Interface | FC (standard) | General Characteristics |
|---|---|
| Power | 2 AA battery (Standby Time > 24H) |
| Operation environment | –15 ~ +55 °C; 0~95% (no condensation) |
| Storage environment | –40 ~ +70 °C; 0~95% (no condensation) |
| Size | 62 × 22 × 110 mm |
| Weight | 100 g |
