Overview
9 kg 110, 220 V Warranty: 36 months
Desktop 2-channel phosphor digital oscilloscope with 100 MHz bandwidth, 2 GSa/s real-time sample rate, 140 MB memory, 8.0" display and up to 60,000 waveforms/sec capture rate.
Discontinued
Contact
sales team
Compare
Compare
Discontinued
Contact
sales team
Impossible to estimate the shipping cost

You may also like

Digital Oscilloscope SIGLENT SDS2102X Plus
Add to wishlist
Digital Oscilloscope SIGLENT SDS2102X Plus
USD 999.00
USD 891.00
Add to wishlist
Add to cart
2 channel Super Phosphor Oscilloscop with a 100 MHz bandwidth, a sample rate of 2 GSa/s, a maximum memory depth of 200 MB and a 10.1" display.
Availability in stock: HK
Shipping cost
ID: 893077 9 kg
Mixed Signal Oscilloscope OWON MSO8102T
Add to wishlist
Mixed Signal Oscilloscope OWON MSO8102T
USD 830.00
Add to wishlist
Add to cart
Dual-channel mixed signal oscilloscope with 100 MHz bandwidth, up to 2 GSa/s real-time sample rate, 16-channel Logic Analyzer with 100 MHz bandwidth, and 8" display.
Availability in stock: HK
Shipping cost
ID: 856645 5 kg 110, 220
Digital Oscilloscope RIGOL DS2102A
Add to wishlist
Digital Oscilloscope RIGOL DS2102A
USD 629.00
USD 566.10
Add to wishlist
Add to cart
Dual-channel digital oscilloscope with 100 MHz bandwidth, 2 GSa/s real-time sample rate, 8" display and 50,000 waveforms/sec acquisition.
Availability in stock: HK
Shipping cost
ID: 845096 7.5 kg 110, 220
Description

SIGLENT SDS2102X is a 2-channel Super Phosphor Oscilloscope with a bandwidth of 100 MHz, a sample rate of 2 GSa/s, and a 140 Mpts memory depth.

Features

  • New generation of SPO (Super Phosphor Oscilloscope) technology
  • Supports statistics calculations, Gating  measurement, Math measurement, Ref measurement
  • Waveform math function (FFT, addition, subtraction, multiplication, division, integration, differentiation, square root)
  • High Speed hardware based Pass/Fail function
  • Large 8 inch TFT-LCD display with 800*480  resolution
  • Different interfaces: USB Host, USB Device, LAN, Pass / Fail, Trigger Out, GPIB

User Manual

Read more
Description

SIGLENT SDS2102X is a 2-channel Super Phosphor Oscilloscope with a bandwidth of 100 MHz, a sample rate of 2 GSa/s, and a 140 Mpts memory depth.

Features

  • New generation of SPO (Super Phosphor Oscilloscope) technology
  • Supports statistics calculations, Gating  measurement, Math measurement, Ref measurement
  • Waveform math function (FFT, addition, subtraction, multiplication, division, integration, differentiation, square root)
  • High Speed hardware based Pass/Fail function
  • Large 8 inch TFT-LCD display with 800*480  resolution
  • Different interfaces: USB Host, USB Device, LAN, Pass / Fail, Trigger Out, GPIB

User Manual

Download SIGLENT SDS2102X User Manual.

Technical Specifications

  SDS2072X SDS2074X SDS2102X SDS2104X SDS2202X SDS2204X SDS2302X SDS2304X
Channels 2 4 2 4 2 4 2 4
Bandwidth 70 MHz 70 MHz 100 MHz 100 MHz 200 MHz 200 MHz 300 MHz 300 MHz
Sample Rate (max.) 2 GSa/s
Memory Depth 140 Mpts
Math +, -, *, /, FFT, d/dt ,∫dt,√
FFT windows Rectangle, Hanning, Hamming, Blackman
Time base 1 ns/div to 50 s/div
Display 20.32 cm (8") WVGA-Color-LCD, 800 × 480 Pixel
Interface USB Host, USB Device, LAN, Pass/Fail, Trigger Out, GBIP
Size (W × H × D) 352 × 224 × 112 mm
Weight 3.4 kg

Video

Youtube video

You'll find even more video reviews in the Video tab. Go and check it out!

Additional Information

Download SIGLENT SDS2102X Data Sheet.

Package Contents

  • SIGLENT SDS2102X oscilloscope (1 pc.)
  • Probes (2 pcs.)
  • USB cable (1 pc.)
  • Power cable (1 pc.)
  • Quick start guide (1 pc.)
Specifications
Number of channels
  • dual-channel
Bandwidth
  • 100 MHz
Type
  • desktop
  • phosphor
Sample Rate
  • 2 GS/s
Storage Capacity
  • 140 MB
Screen Size
  • 8,0" TFT LCD
