Thermal Imaging Camera FLIR i40
id: 824322
Overview
110, 220 V Warranty: 12 months
120 x 120 pix resolution, temperature range -20 to +150°C, working environment -15 to +50°C, 1 GB memory on SD card, manual focus. Read more
Description
FLIR i40 thermal imaging camera is a diagnostical tool for detecting hidden problems using temperature rise. FLIR i40 thermal imaging camera would be useful in identifying repairing problems, insurance assessments, avoiding electrical faults, heating and cooling systems defects, car service and medicine. Fully automatic affordable thermal imaging camera can be easily connected to PC. The information about the infrared heating appears immediately on large color LCD and does not require any previous experience with such equipment.
FLIR i40 Thermal Imaging Camera Features
- "Picture in picture" mode
- Built-in illuminator lights
- Field replaceable battery
- Thumbnail image gallery
- 0.6 Mp resolution with LED lamps
- Area (min/max) mode
- High accuracy
- 0.1°C thermal sensitivity for thermally sensitive targets
- Light weight, pocket size
- Color LCD with high resolution
- More than 4 hour continuous operation on a single charge
FLIR i40 Thermal Imaging Camera Technical Specifications
Optical data and imaging | |
---|---|
Minimum focus distance | 0.1 m |
Field of view | 25° × 25° |
Spatial resolution | 3.64 mrad |
Thermal sensitivity | < 0.1°C |
Focus | manual |
Image frequency | 9 Hz |
Detector data | |
Spectral range | 7.5 - 13 μm |
Detector type | focal plane array (FPA), uncooled microbolometer |
IR resolution | 120 × 120 pixels |
Measurement | |
Object temperature range | -20°C to +120°C |
Measurement | ±2°C or ±2% of reading |
Spotmeter | center spot |
Emissivity table | predefined materials |
Emissivity correction | variable form 0.1 to 1.0 |
Reflected apparent temperature correction | automatic, depends on reflected temperature input |
Color palettes | black and white, iron and rainbow |
Image storage and data communication interfaces | |
File formats | .jpeg, 14-bit measurement data included |
Storage medium | microSD card |
Interfaces | USB mini-B, USB-A |
General information | |
Battery | rechargeable Li-Ion battery, 3.6 V operation time approx. 5 hours AC adapter |
Display | color LCD, 3.5" |
Dimentions, mm | 235 × 81 × 175 |
Weight | 0.6 kg (battery included) |
Additional Information
Download FLIR FLIR i40 Data Sheet.
FLIR i40 Thermal Imaging Camera Package
- Thermal imaging camera FLIR i40
- USB mini-B cable
- MicroSD card (1 GB)
- MiniSD adaptor
- Hand strap
- Lens cap
- Li-Ion rechargeable battery
- 90-260 V AC adaptor /charger with EU, UK, US and Australian plugs
- QuickReport software
- Hard case
