Digital Oscilloscope Rigol DS1022C
Overview
Description
Specifications
Delivery
Payment
Warranty
Discontinued
Find substitute
Overview
4.7 kg 110, 220 V Warranty: 36 months
Dual channel digital oscilloscope with bandwidth – 25 MHz, real-time sample rate – 400 MSa/s, equivalent sample rate – 25 GSa/s.
Discontinued
Find substitute
Compare
Compare
Discontinued
Find substitute
Impossible to estimate the shipping cost

You may also like

Digital Oscilloscope RIGOL DS1052E
Bestseller
Add to wishlist
Digital Oscilloscope RIGOL DS1052E
USD 389.00
Add to wishlist
Add to cart
50 MHz bandwidths, 1 GSa/s maximum real-time sample rate, 10 GSa/s maximum equivalent-time sample rate and 1Mpts long memory depth.
Bestseller
Availability in stock: HK
Shipping cost
ID: 811980 7.5 kg 110, 220
Description

RIGOL DS1022C digital oscilloscope provides exceptionally accurate waveform viewing and measurements in a compact, lightweight package. RIGOL DS1022C is ideal for production tests, field service, research, design and all other applications involving analog/digital circuits test and troubleshooting, as well as education and training.

RIGOL DS1022C Digital Oscilloscope Features

  • Ultra compact design, small dimensions
  • Bandwidth: 25 MHz
  • Dual channels
  • Real-time sample rate: 400 MSa/s maximum
  • Equivalent time sample rate: 25 GSa/s maximum
  • Memory depth: 1 M points (Single Channel), 512 K points (Dual Channels)
  • 20 automatic measurements
  • Versatile trigger modes: Edge, Pulse, Slope, Video, Alternate
  • Adjustable trigger sensitivity
  • 10 waveforms, 10 setups, BMP and CSV storage
  • Math functions: Add, Subtract, Multiply, FFT
  • Automatic self calibration
  • Special digital filter and waveform recorder
  • Built-in hardware frequency counter
  • 5.7' color LCD
  • Standard interface: USB Device, RS-232; USB Host, to support USB flash memory and USB printer
  • Multi-language user interface, built-in help system

RIGOL DS1022C Digital Oscilloscope User Manual

Download RIGOL DS1022C digital oscilloscope user manual

RIGOL DS1022C Digital Oscilloscope Technical Specifications

Bandwidth 25 MHz
Real time sample rate 400 MSa/s
Equivalent sample rate 25 GSa/s
Memory depth
  • 1M points (single channel)
  • 512K points (dual channels)
  • 512K points (logic analyzer)
Rise time 14 ns
Time base range 20 ns/div - 50 s/div
Trigger modes Edge, Video, Pulse Width, Slope, Alternate
Input impedance 1 M Ω || 13 pF
Vertical sensitivity 2 mV/div - 5 V/div
Vertical resolution 8 bits
Maximum input voltage 400 V (DC+AC peak)
Automatic measurements Vpp, Vmax, Vmin, Vtop, Vbase, Vamp, Vrms, Vavg, Vover, Vpre, Freq, Period, Rise, Fall, +Width, -Width, +Duty, -Duty, DelayA, DelayB
Math Add, Subtract, Multiply, FFt
Storage
  • internal: 10 waveforms and 10 setups
  • USB: BMP, CSV, waveforms and setups
Display 5.7-inch color LCD, 320 x 234
Power source 100-240 V / 50 VA max
Weight 2.3 kg
Dimensions 303 x 154 x 133 mm

RIGOL DS1022C Digital Oscilloscope Package

  • RIGOL DS1022C digital oscilloscope (1 pc.)
  • Power cable (1 pc.)
  • Test leads (2 pcs.)
  • USB data cable (1 pc.)
  • User manual (1 pc.)
  • Software (1 pc.)
Read more
