Overview
Rate product
9 kg 110, 220 V Warranty: 36 months
Desktop 2-channel mixed-signal digital oscilloscope with 70 MHz bandwidth, 2 GSa/s real-time sample rate, 28 MB of memory depth. Built-in waveform generator. Read more
Discontinued
Find substitute
Compare
Compare
Discontinued
Find substitute
Impossible to estimate the shipping cost

You may also like

Desktop 2-channel phosphor digital oscilloscope with 200 MHz bandwidth, 2 GSa/s real-time sample rate, 28 Mpts memory, 7.0" display and up to 400,000 waveforms/sec capture rate.
Availability in stock: HK
Shipping cost
ID: 887344 6 kg
2 channel Super Phosphor Oscilloscop with a 100 MHz bandwidth, a sample rate of 2 GSa/s, a maximum memory depth of 200 MB and a 10.1" display.
Availability in stock: HK
Shipping cost
ID: 893077 9.8 kg
Description

SIGLENT SDS2072 is a desktop dual-channel mixed-signal digital oscilloscope with maximum bandwidth of 70 MHz. 8-inch TFT color LCD of the oscilloscope ensures bright and vivid waveform representation and backlit buttons ensure user comfort. SIGLENT SDS2072 has up to 28 MB of memory and waveform capture rate up to 110,000 waveforms per second.

Features

  • Bandwidth: 70 MHz.
  • 2 channels.
  • Real-time sample rate: 2 GSa/s.
  • Memory depth: 28 MB.
  • Built-in 25 MHz function/arbitrary waveform generator.
  • Innovative SPO (Super Phosphor Oscilloscope) technology for increased measurement accuracy and rate.
  • Vertical sensitivity range: 2 mV/div – 10 V/div.
  • Trigger types: Edge, Pulse, Video, Slope, Interval, Runt, Window, Pattern, DropOut, Series Protocol Trigger.
  • 8" TFT color LCD, bright and vivid waveform display.
  • Support for HDTV trigger.
  • Support history function and segmented memory with up to 80,000 frames.
  • Hardware-based zoom function.
  • High speed pass/fail function technology.
  • 32 kinds of automatic waveform measurements with support measurement statistics function.
  • Advanced waveform math operations (FFT, differential, integral and square root)
  • Complete connectivity: USB host, USB device (USBTMC, PictBridge, LAN (VXI-11), EXT TRIG, PASS/FAIL, TRIG OUT.
  • Multi-language user interface and built-in online help system.

Video

Youtube video

You'll find even more video reviews in the Video tab. Go and check it out!

Technical Specifications

Bandwidth 70 MHz
Channels 2
Real time sample rate Max: 2 GSa/s
Memory depth 28 MB
Vertical sensitivity range 2 mV/div – 10 V/div
Vertical resolution 8 bits
Rise time ≤1.2 ns
Time base range 1.0 ns/div – 50 s/div
Math A+B, A-B, AxB, A/B, FFT, Diff, Intg, Sqrt
Trigger types Edge, Pulse, Video, Slope, Interval, Runt, Window, Pattern, DropOut, Series Protocol Trigger
Storage Internal: 2 sets of reference waveforms, 20 sets of setups, 20 sets of captured waveforms (store/recall function)
Input coupling DC, AC, GND
General Characteristics
Display 8" TFT color LCD (800 × 480)
Interface USB Host (supports USB-GPIB), USB Device, LAN, EXT TRIG, Aux (TRIG OUT/Pass/Fail)
Power source 100 ~ 240 V AC
Weight 3.5 kg
Dimensions 352 × 112 × 224 mm

Additional Information

Download SIGLENT SDS2072 Data Sheet.

Package Contents

  • SIGLENT SDS2072 oscilloscope (1 pc.)
  • 1:1/10:1 probes (2 pcs.)
  • USB cable (1 pc.)
  • Power cable (1 pc.)
  • CD with user manual and software (1 pc.)
